VL-Inclinometer

The VL-Inclinometer is a digital roll sensor that can be installed on vessels and cruises. The power supply and the serial interfaces are galvanic isolated.

The system fulfills the following standards:
– ISO/PAS 19697:2014
– ISO/DIS 19697
– IEC60945
– IEC61162-2
– IEC61162-450

(BSH 4543/001/6013006/16)

The measured results are transmitted as NMEA through two serial Interfaces (RS422). The device sends the following standard telegrams: $–HRM, $–XDR and  $–ALR. The status is indicated by three LED’s.
